Machine tool components from CYTEC – all catalogues at a glance

On this page you can download all current CYTEC catalogues and brochures for machine tool components as PDF files. The download area covers the complete range of high-tech machine tool components for automation solutions and production machines: CYMILL milling heads and heavy duty machining heads for 5-axis machining, CYTURN 2-axis NC rotary tables with torque motor technology, FSW spindles for friction stir welding, hydraulic clamping systems, CYLOCK and CYSTOP locking cylinders as well as CYPULL core-pull cylinders for injection moulds.

Each catalogue contains detailed technical data, dimensions, order codes and application examples for our machine tool components. CYTEC Zylindertechnik has been developing and manufacturing key components for the international machine tool market for more than 35 years – used in tool and mould making, the automotive industry, aviation and aerospace engineering. All products are engineered and built at our German headquarters, CYTEC Zylindertechnik GmbH. If you need a printed catalogue or advice on selecting the right component, please contact our team directly.

Which catalogue is right for you?

If you are planning a new machining centre or retrofitting an existing machine, start with the overview catalogue: it presents all CYTEC machine tool components in one document and helps you compare the product families before going into detail. For milling applications on gantry and portal machines, the CYMILL HD catalogue covers heavy duty machining heads with high torque and rigidity, including automatic head changing systems. Workpiece positioning is covered by the CYTURN catalogue: 2-axis NC rotary tilting tables with backlash-free torque motor drives for simultaneous 5-axis machining.

Manufacturers joining aluminium structures – for example battery trays, heat exchangers or aerospace panels – will find the right spindle technology in the FSW brochure for friction stir welding. The spindle repair brochure explains our service process for motor spindles: inspection, bearing replacement, balancing and test-run protocols, for CYTEC spindles as well as third-party makes.

On the hydraulics side, the clamping technology catalogue documents clamping elements for shafts, rods and linear guides, while the CYLOCK / CYSTOP catalogue covers mechanically locking cylinders that hold axes and vertical loads safely even at zero pressure. Injection moulders should download the CYPULL catalogue: locking core-pull cylinders that reduce mould size and cycle times. All PDFs are free of charge and always reflect the current product status – no registration required.
